Onkyo GXW-5.1 Service Manual

PRINTED CIRCUIT BOARD PARTS LIST
DSP CIRCUIT PC BOARD (NADG-7058-1B)
CIRCUIT NO. PART NO. DESCRIPTION CIRCUIT NO. PART NO. DESCRIPTION
ICs Sockets
Q701 22241520R2 AK4112AVF P702B 25052322 or NSCT-22P2219 or
Q703 22241399R2 TC7WU04F 25052516 NSCT-22P2413
Q704 22241340R9 CS492604-CL P705 25051238 NSCT-13P1028
Q705,Q706 22274574ER2O TC74VHC574FT P706 25051235 NSCT-10P1025
Q707 22241596R3 or MBM29F002TC-90PFTN or Jacks
22241591R3 MX27C2000 P7201 25045641 NPJ-2PDR446, Line input
Q708 222740077R2O TC74HCT7007AF P7202 25045473 NPJ-1PDBL291, Coaxial input
Q709 22278033DR2NE MPC2933T Photo coupler
Q710 22274000GR2O TC74VHCT00AFT U7201 24120037 TORX178B, Digital input
Q7201 222740046R2O TC74HCU04F Resonators
Q801 22241529R3 AK4527VQ X701 3010327 or AT-4912.288MHz
Q803-Q808 22241383R2 NJM4565M-D 3010320 or
Diodes 3010335
D801-D811 223234R2 or 1SS352 or Oscilator
223269R2 1SS355, Chip X702 3010324R2 CSTCV12.2MTJ0C4
Coils
L701-L703, 231237M022R2 NCH-1471 POWER AMPLIFIER CIRCUIT PC BOARD (NAAF-7059-1B)
L720,L7201, CIRCUIT NO. PART NO. DESCRIPTION
L7202,L721-L724, ICs
L802,L803 Q301 22241371 TC9482N
L704,L705 230921R2 Q302-C304,Q316 22241383R2 NJM4565M-D
Capacitors Q501-Q503 ! 22241679 TDA8563AQ
C701,C708, 354721019 100uF,6.3V,Elect. Q901,Q902 222780125JRC or NJM78M12FA or
C7203,C740-C741, 222780125MAT or AN78M12F or
C767,C768,C770 222780125NEC MPC78M12HF
C788,C791 354724719 470uF,6.3V,Elect. Transistors
C807,C810 354722219 220uF,6.3V,Elect. Q305-Q312, 2213631 or RN1241-A or
C811,C840,C842 354742219 220uF,16V,Elect. Q314 2213632 RN1241-B
C812,C813,C830, 354784709 47uF,50V,Elect. Q313,Q514 2216350R2 or KRA107S or
C831,C844,C845, 2216360R2 RN2407
C858,C859 Q507,Q513, 2216340R2 or KRC107S or
C816,C817,C833, 374721524 0.015uF+/-5%,50V, Plastic Q510 2216260R2 RN1407
C846,C847, Q508 2216230R2 or KRA103S or
C860,C861 2214540R2 RN2403
C825 355741009 10uF,16V,Elect. Q509 2216175R2 or KTC3875-GR or
C827,C829 354744709 47uF,16V,Elect. 2213145R2 2SC2712-GR
C832 374721544 0.1uF+/-5%,50V, Plastic Q511 2215975 or KTA1266-GR or
C834,C836 374726834 0.068uF+/-5%,50V, Plastic 2211455 2SA1015-GR
C835,C837,C848, 374726814 680pF+/-5%,50V, Plastic Q512 2213640 or DTC123JS or
C849,C850,C851 2215830 KRC105M
C862-C865 Q516 2203434 KTD2061-Y
C868,C869 354742209 22uF,16V,Elect. Diodes
D301,D502, 223234R2 or 1SS352 or
D504 223269R2 1SS355, Chip
D506 224491300R2 UDZ13B or
D905-D908 22380260 or RL1N4003 or
22380035 GP104003E, Zener
-1-
