5
Getting to know Your Speaker Package
—Continued
D
STANDBY/ON indicator
Red: Subwoofer in standby mode
Blue: Subwoofer on
With the Auto Standby function, the SKW-518/
SKW-501 automatically turns on when an input sig-
nal is detected in Standby mode. When there’s no
input signal for a while, the SKW-518/SKW-501
automatically enters Standby mode.
E
OUTPUT LEVEL control
This control is used to adjust the volume of the sub-
woofer.
F
LINE INPUT
This RCA input should be connected to the sub-
woofer pre out on your AV receiver with supplied
RCA cable.
Note:
The Auto Standby function turns the subwoofer on when
the input signal exceeds a certain level. If the Auto
Standby function does not work reliably, try slightly
increasing or decreasing the subwoofer output level on
your receiver.
If the subwoofer is placed on a hard floor (wood, vinyl,
tile, etc.) and playback is very loud, the subwoofer's feet
may damage the flooring. To prevent this, place the sup-
plied pads underneath the subwoofer's feet. The pads
also provide a stable base for the subwoofer.
Subwoofer (SKW-518/SKW-501)
4
■ Front
SKW-518 SKW-501
4
56
To AC outlet
SKW-518/SKW-501
■ Rear
Using the Floor Pads for Subwoofer
Pad
SKW-501SKW-518
HTP-518SKS-HT518En.fm Page 5 Wednesday, March 12, 2008 3:57 PM
To Next Page
