Onkyo LS-T10 User Manual

5
3. Connect all cables to the unit.
(o See 7 to 8 pages)
4. Mount the TV on the center of the top face of this unit.

Mount the unit correctly by referring to the figure below.
Mountable range of the TV Stand

Adjust the TV stand position within the shaded area.

Place the TV stand in such a way that its center matches that of this unit.
Shaded area: Mountable range

Onkyo LS-T10 Specifications

General

FM radio	-
Product color	Black
Recommended usage	Home theatre
Woofer diameter	120 mm
Number of woofer drivers	1
Full-range driver diameter	70 mm
Number of full-range drivers	6
Audio decoders	Dolby Digital
RMS rated power	- W
Audio output channels	- channels
Manual	Yes
Frequency range	150 - 20000 Hz
Soundbar dimensions (WxDxH)	700 x 350 x 105 mm
Bluetooth version	2.1+EDR
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Subwoofer frequency range	20 - 150 Hz
Cables included	Audio (3.5mm)
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	21 W
Package weight	12400 g

Weight and Dimensions

Soundbar weight	8700 g
