Onkyo SKW 50 User Manual

SKW-50
PARTS LIST
EXPLODED VIEW
REF NO. PART NO. DESCRIPTION
A1 27160467 Heat sink
A3 27130745 Bracket
A6 27141661 Retainer
A8 28184777 Cover
A11 29-100-076-21 Cushion
A12 28141475 t2X5X160,Cushion
A13 28141476 t2X5X80,Cushion
A14 27122895A Rear panel
A16 830440109 4TTC+10C(BC),Self tapping screw
A17 28141473 t2X5X415,Cushion
A18 28141474 t2X5X195,Cushion
A19 28141334 Cushion
A20 27301941 Cord,bushing
A22 260208 Binder
A23 223021 TBM-51W 9043,Isolation sheet
B2 W20170A Speaker ass'y
B3 AZ200003-01 Cabinet ass'y
B7 31-000-038-61
㱢
105-
㱢
115 L=195,Paper duct
B8 29-100-076-11 Cushion
B9 51-000-119-01 Box ass'y
B10 AZ000084-01 Base ass'y
B14 54-000-122-01 VHZ 30t*150*150,Sound absorbent
B16 58-000-301-01 Cover
B17 57-000-581-01 Panel
B18 58-000-302-01 Foot
B19 58-000-303-01 Knob(A)
B20 58-000-304-01 Knob(B)
B23 70-015-450-01
㱢
4*50,Self tapping screw
B24 70-015-414-01
㱢
4*14,Self tapping screw
B27 71-079-800-03 Nuts
F901 252159 or 2A-UL/T-237,Fuse
252253 2A-T/UL-ST2,Fuse
P535 2009990611UL NSAS-2P0833,Socket
P901 253272HIT AS-UC-6#18,Power supply cord
Q515 2203063 or 2SC5198-O,Transistor
2203062 or 2SC5198-R,Transistor
2202524 or 2SC4468-Y,Transistor
2202526 or 2SC4468-P,Transistor
2202523 2SC4468-O,Transistor
Q516 2203053 or 2SA1941-O,Transistor
2203052 or 2SA1941-R,Transistor
2202514 or 2SA1695-Y,Transistor
2202516 or 2SA1695-P,Transistor
2202513 2SA1695-O,Transistor
Q541 2202104 or 2SC3423-Y,Transistor
2202103 2SC3423-O,Transistor
Q951 2202754 2SD1266-P,Transistor
Q952 2202764 2SB941-P,Transistor
R602 4000144 PTH9M04-2.2K,Thermistor
T901 2301487 NPT-1396D,Power transformer
U1 1W204565-2D NAAF-6865-2D,Main PC board ass'y
U2 1W204566-2D NAAF-6866-2D,Input/Output PC board ass'y
U3 1W204567-2D NAAF-6867-2D,OP amplifier PC board ass'y
U4 1W204568-2D NAAF-6868-2D,Power supply PC board ass'y
U5 1W204569-2D NAAF-6869-2D,Power transformer PC board ass'y
U7 1W204571-2D NAAF-6871-2D,Volume PC board ass'y
U8 1W204572-2D NAAF-6872-2D,PC board for holder
U9 1W204573-2D NAAF-6873-2D,Standby LED PC board ass'y
B25 70-015-420-02 4 x 20,Self tapping screw
