Turn the Jog switch to
select from either ON or OFF.
Press the MODE
key 5 times.
Turn the Jog switch
4 times toward the
‘
’ direction.
Press the
Jog switch.
Turn the Jog switch
4 times toward the
‘’ direction.
Press the
Jog switch.
Press the
Jog switch.
Press the MODE key
3 times or keep it pressed
for 2 sec. or more.
The digital display will quickly
blink 3 times to confirm the setting.
8-5. Selection for Communication Change to Permit / Not to Permit
1 Press the [MODE key] 5 times to select ‘PRO mode’.
2 Turn the [Jog switch] 4 times toward the
‘’ direction, to
select ‘PRO4 mode’.
3 Press the [Jog switch] to enter the ‘setting condition copy
setting’ state.
4 Turn the [Jog switch] 4 times toward the ‘
’ direction, to
enter the ‘selection for communication change to permit / not
to permit’.
5 If the [Jog switch] is pressed, the current setting will be
displayed.
* The factory setting is ‘Lock OFF’.
6 If the [Jog switch] is turned, the digital display will blink.
Select from either ‘ON’ or ‘OFF’.
7 If the [Jog switch] is pressed, the digital display will quickly
blink 3 times, confirming the setting.
8 Press the [MODE key] 3 times or keep it pressed for 2 sec.
or more, the amplifier will return to ‘RUN mode’ (normal
sensing operation).
If the optical communication setting change function has been locked when attempting to carry out copy / load /
save operations on all amplifiers at once using the setting condition copy function, remote data bank setting
function or remote data bank save setting function while in PRO mode, only the amplifier being configured will be
locked. As a result, copy / load / save operations can be carried out except the locked units.
