23 GB/IE
Scope of delivery
1 Laser distance measurer
2 1.5 V-batteries LR03 (AAA)
1 Instructions for use
Technical data
Measurement range: 0.075–20 m* (reference point
top side)
0.175–20 m* (reference point
bottom side)
Measuring accuracy (typical): ± 3,0 mm**
Smallest display unit: 1 mm
Operating temperature: 0 °–40 °C (For indoor use)
Relative humidity max.: ≤ 75 %
Laser category: 2
Wavelength of the laser (λ): 620–690 nm
Maximum power P max: <1 mW
Operating voltage: 3 V
(Direct current)
Batteries: 2 x 1.5 V LR03 (AAA)
Weight: 72 g (without batteries)
Dimensions: 10 x 3.8 x 2.45 cm
Degree of protection: IP20
*) The range improves the better the laser light is returned from
the surface of the target (dispersing, not refl ecting) and the
brighter the laser is compared to the ambient light (interior
rooms, twilight).
**) In unfavourable conditions such as strong sunlight or poorly
refl ective surfaces, the maximum deviation is ± 8 mm at 20 m.
In favourable conditions, a deviation influence of ± 0.1 mm/m
must be taken into account.
