Parkside PWS 20 A1 User Manual

17
GB IE
General description
The illustration of the principal
functioning parts can be found
on the front and back foldout
pages.
Extent of the delivery
Carefully unpack the appliance and check
that it is complete.
The appliance is supplied with the motor
head tted (
4). To remove the motor
head, open the sealing clips (
6).
Dispose of the packaging material cor-
rectly.
4 Motor head
7 Container
8 4 castors with accessory holders
11 Foam lter
12 Paper lter bag
14 Suction pipe (2 parts)
16 Suction hose
20 Floor nozzle
21 Crevice nozzle
22 Upholstery nozzle
23 Washer nozzle for cleaning up-
holstery
24 Washer nozzle with attachment
for hard surfaces
25 Phillips screw
- Instruction Manual
Overview
Housing
1 Carrying handle (not visible)
2 On/Off switch
3 Pump switch
4 Motor head with lter basket
(4a)
5 Water duct connector
6 Fastening clip
7 Container
8 4 castors with accessory holders
(8a)
9 Mains connection cable
10 Suction connector
Filters
11 Foam lter for wet suction
12 Paper lter bag to vacuum
coarse dirt
Accessories
13 Water duct at the suction pipe
13a Release
14 Suction pipe
15 Handle with air regulation
16 Suction hose
17 Water duct at the suction hose
18 Notch
19 Water tank
19a Water tank lid
Nozzles
20 Floor nozzle
21 Crevice nozzle
22 Upholstery nozzle
23 Washer nozzle for cleaning up-
holstery
24 Washer nozzle with attachment
for hard surfaces
25 Phillips screw
Description of operation
The carpet cleaner is equipped with a sta-
ble stainless steel container for collecting
dirt and a separate water container for the
washer function. The castors provide good
manoeuvrability of the appliance. The suc-
tion ow is switched off by a oat during
wet vacuuming once the waste tank is full.
The following describes the function of the
operating parts.
