Philips Azur Performer RI3802/22 User Manual

RI3802/22 / RI3802/24
2-5
Disassembly advice
BACKPLATE SCREW COVER STICKER 1
BACKPLATE 2, SWIVEL 4
POWER CORD 3
LAMP ASSY 5
Remove BACKPLATE COVER STICKER 1
Remove Screws A1, A2, A3
Remove BACKPLATE 2 & SWIVEL 4
Remove Screw B1, B2
Remove CORD CLAMP
Remove POWER CORD 3
Remove LAMP ASSY 5
FILLING DOOR 6
INLAY 8
SPRAY KNOB 10
TRIGGER & TRIGGER HOLDER 13
Remove BACKPLATE COVER STICKER 1
Remove Screws A1, A2, A3
Remove BACKPLATE 2 & SWIVEL 4
Remove Screw B1, B2
Remove CORD CLAMP
Remove POWER CORD 3
Remove LAMP ASSY 5
Remove FILLING DOOR 6
Remove Screw C1
Remove INLAY 8
Remove SPRAY KNOB 10
Remove Screw D1, D2, D3
Remove TRIGGER & TRIGGER HOLDER 13
HOUSING 11
CAM LEVER 14
T-DIAL INDICATOR 16
WATER TANK ASSY 17
COVER 19
SOLEPLATE ASSY 23
Remove BACKPLATE COVER STICKER 1
Remove Screws A1, A2, A3
Remove BACKPLATE 2 & SWIVEL 4
Remove Screw B1, B2
Remove CORD CLAMP
Remove POWER CORD 3
Remove LAMP ASSY 5
Remove FILLING DOOR 6
Remove Screw C1
Remove INLAY 8
Remove SPRAY KNOB 10
Remove Screw D1, D2, D3
Remove TRIGGER & TRIGGER HOLDER 13
Remove Screw E1, E2
Remove HOUSING 11
Remove CAM LEVER 14
Remove Screw F1
Remove T-DIAL INDICATOR 16
Remove Screws G1, G2
Remove WATER TANK ASSY 17
Remove Screws H1, H2, H3
Remove COVER 19
Remove SOLEPLATE ASSY 23
