Philips PerfectCare Pure PSG User Manual

GC7620
2-8
INLAY 10
IRON PCBA 6
TRIGGER 9
CHASSIS 8
HOUSING & LIGHT RING ASSY 4
DOSING HEAD 2
Remove Screw A1
Remove INLAY 10
Remove Screw B1
Remove IRON PCBA 6
Remove TRIGGER 9
Remove Screws C1, C2
Remove CHASSIS 8
Remove Screws D1, D2, D3
Remove HOUSING & LIGHT RING ASSY 4
Remove DOSING HEAD 2
LED ASSY 5
HOSE CORD MTD ASSY 7
COVER 3
SOLEPLATE ASSY 1
Remove Screw A1
Remove INLAY 10
Remove Screw B1
Remove IRON PCBA 6
Remove TRIGGER 9
Remove Screws C1, C2
Remove CHASSIS 8
Remove Screws D1, D2, D3
Remove HOUSING & LIGHT RING ASSY 4
Remove DOSING HEAD 2
Remove LED ASSY 5
Remove Screw E1
Remove HOSE CORD MTD ASSY 7
Remove Screws F1, F2, G1
Remove COVER 3
Remove Screws H1, H2
Remove SOLEPLATE ASSY 1
DISASSEMBLY ADVICE - IRON
PARTS LIST - IRON
Pos Service code Description
1
2
3
4
5
4239 021 77141
4239 026 53721
4239 026 53733
4239 021 79893
4239 021 78811
Soleplate MTD assy
Dosing head
Cover
Housing & Light ring assy
LED assy
6
7
8
9
10
4239 021 77592
4239 021 79913
4239 026 53774
4239 026 56114
4239 026 53813
Iron PCBA
Hose cord MTD assy
Chassis
Trigger
Inlay
11 4239 021 79932 Deco plate assy
