PIAGGIO MP3 125 User Manual

04_01
TECHNICAL DATA FOR MP3 125 EURO3
Electronic ignition capacitative, with variable timing
and separate HV coil
Fuel supply Unleaded petrol; depression
carburettor, electric pump or
vacuum pump.
Transmission With automatic expandable pulley
variator with torque server, V belt,
self-ventilating automatic
centrifugal dry clutch, gear
reduction unit and transmission
housing with forced air circulation
cooling.
84
4 Technical data

PIAGGIO MP3 125 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Liquid cooled
Fuel System	Electronic fuel injection
Max Power	11 kW (15 HP) @ 9, 250 rpm
Rear Brake	240 mm disc
Seat Height	780 mm
Fuel Tank Capacity	12 liters
Length	2, 140 mm
Wheelbase	1, 490 mm
Max Torque	12 Nm @ 7, 250 rpm
Transmission	CVT
Rear Suspension	Dual hydraulic shock absorbers
Front Brake	2 x 240 mm discs
