Wheel hub
Unscrew the indicated clamps and using the tool
remove the hub.
Specific tooling
038137Y Rear Hub Extractor
Planetary and half-pins
In order to optimise the joint of the axle shaft, be
careful:
- when refitting the two half-pins;
- that the most open part is facing the axle
shaft.
Ball bearing and split ring on hub
Heat the housing area with the appropriate tools
and fit the ball bearing and the remaining parts.
Specific tooling
020151Y Heat gun
MSS APE 50 Suspensions
SS - 99
