Remove the plastic panel at the location
of the arrows.
Remove the orginal radio bracket.
Remove the panel around the gear lever.
Remove the two screws and remove the
original dashboard by using a plastic
wedge.
Connect all of the needed wiring harnesses and check the connections carefully.
12
3
Place the 2-Din metal bracket and tighten
the bracket by four screws.
4
Place the headunit and replace the
panels.
5
2-DIN 12.301179-09
