37
DEH-1100,11
R 651 RS1/8S222J
R 655 RS1/10S103J
R 656 RS1/10S103J
R 657 RD1/4PU102J
R 658 RD1/4PU102J
R 660 RS1/10S1R0J
R 681 RD1/4PU681J
R 682 RS1/10S102J
R 683 RD1/4PU102J
R 684 RS1/10S102J
R 699 RS1/10S0R0J
R 725 RS1/10S0R0J
R 901 RS1/10S473J
R 902 RD1/4PU103J
R 903 RD1/4PU103J
R 904 RS1/10S473J
R 905 RS1/10S102J
R 906 RS1/10S473J
R 907 RS1/10S473J
R 908 RS1/10S472J
R 909 RD1/4PU103J
R 911 RS1/10S122J
R 912 RD1/4PU103J
R 914 RD1/4PU152J
R 916 RS1/10S221J
R 918 RS1/10S1R0J
R 941 RD1/4PU472J
R 942 RD1/4PU152J
R 981 RS1/10S472J
R 982 RS1/10S222J
R 983 RD1/4PU221J
R 984 RD1/4PU221J
CAPACITORS
C 310 CKSQYB105K16
C 311 CKSQYB104K16
C 312 CEJA2R2M50
C 313 CKSQYB105K16
C 314 CKSYB104K16
C 315 CKSQYB102K50
C 316 CKSQYB102K50
C 317 CEJA100M16
C 318 CEJA100M16
C 319 CKSQYB822K50
C 320 CKSQYB822K50
C 321 CEAL1R0M50
C 322 CEJA1R0M50
C 323 CKSQYB183K50
C 324 CKSQYB183K50
C 325 CKSQYB104K16
C 326 CKSQYB104K16
C 327 CKSQYB104K16
C 328 CKSQYB104K16
C 329 CEJA2R2M50
C 330 CEJA4R7M50
C 332 CKSQYB473K16
C 333 CKSQYB104K16
C 334 CKSQYB104K16
C 335 CEAL470M10
C 340 CEAL2R2M50
C 341 CEJA2R2M50
C 350 CEJA330M10
C 361 CEJA2R2M50
C 362 CKSYB225K16
C 363 CEJA100M16
C 364 CKSYB474K16
C 365 CKSQYB474K16
C 366 CKSYB474K16
C 367 CKSQYB474K16
C 368 CKSQYB474K16
C 369 CKSYB474K16
C 370 CKSQYB474K16
C 371 CKSYB474K16
C 372 CKSQYB225K10
C 390 CKSQYB104K16
C 391 3300µF/16V CCH1368
C 411 CKSQYB223K25
C 412 CKSQYB223K25
C 413 CKSQYB102K50
C 414 CEJA220M10
C 415 CKSQYB473K16
C 416 CEAL101M10
C 417 CKSQYB472K50
C 462 CKSQYB183K25
C 463 CKSQYB183K25
C 490 CKSQYB103K50
C 499 CKSQYB103K50
C 611 CKSQYB104K16
C 612 CEJA4R7M35
C 613 CKSQYB473K16
C 614 CKSQYB102K50
C 628 CCSQCH150J50
C 629 CCSQCH150J50
C 630 CKSQYB473K16
C 631 CEAL2R2M50
C 650 CKSQYB104K16
C 901 CEJA101M10
C 902 CKSQYB473K16
C 903 470µF/16V CCH1331
C 904 CKSQYB473K16
C 905 330µF/16V CCH1326
C 906 CKSQYB103K50
C 907 CEJA101M16
C 941 CKSQYB473K16
C 981 CEJA101M10
C 982 CKSQYB102K50
C 983 CKSQYB473K16
Unit Number : CWE1501
Unit Name : FM/AM Tuner Unit
MISCELLANEOUS
IC 1 IC PML002A
IC 2 IC PM4008A
IC 3 IC BR9010FV
Q 1 Transistor 2SC4081
Q 2 Transistor DTC124EU
Q 3 FET 3SK263
Q 51 Transistor 2SC4081
Q 201 FET 2SK932
Q 202 Transistor DTC124EU
Q 204 Transistor 2SC4081
D 1 Diode KV1410(23)
D 2 Diode 1SV248
D 6 Diode KV1410(23)
D 201 Diode DAN217U
D 202 Diode DAN217U
D 903 Diode KV1410(23)
D 904 Diode SVC253
L 1 Coil CTC1155
L 3 Inductor LCTB1R5K2125
L 4 Coil CTC1155
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
B
To Next Page
