4 Push MULTI-CONTROL left or right to
select the cut-off frequency (crossover fre-
quency) of the selected speaker unit (fil-
ter).
Each time MULTI-CONTROL is pushed left or
right, cut-off frequencies (crossover frequen-
cies) are selected in the following order:
! High-LPF
5k—6.3k—8k—10k—12.5k—16k—20k
! High-HPF
800Hz—1k—1.25k—1.6k—2k—2.5k—
3.15k—4k—5k—6.3k—8k—10k—12.5k—
16k
! Mid-LPF, Low-LPF and SW-LPF
25Hz—31.5Hz—40Hz—50Hz—63Hz—
80Hz—100Hz—125Hz—160Hz—200Hz—
250Hz—315Hz—400Hz—500Hz—630Hz
—800Hz—1k—1.25k—1.6k—2k—2.5k—
3.15k—4k—5k—6.3k—8k—10k—12.5k—
16k—20k
! Mid-HPF, Low-HPF and SW-HPF
20Hz—25Hz—31.5Hz—40Hz—50Hz—
63Hz—80Hz—100Hz—125Hz—160Hz—
200Hz—250Hz—315Hz—400Hz—500Hz
—630Hz—800Hz—1k—1.25k—1.6k—2k
—2.5k—3.15k—4k—5k—6.3k—8k—10k
—12.5k—16k
# You cannot select speakers that are set to off
in the initial setting. Refer to Setting the speakers
on page 35.
5 Push MULTI-CONTROL up or down to
adjust the level of the selected speaker
unit (filter).
Each time MULTI-CONTROL is pushed up or
down, the level of the selected speaker unit (fil-
ter) increases or decreases.
0dBto –24 dB is displayed as the level is in-
creased or decreased if you have selected
High-LPF, High-HPF, Mid-LPF or Mid-HPF.
6dBto –24 dB is displayed as the level is in-
creased or decreased, only if you have se-
lected Low-LPF, Low-HPF, SW-LPF or
SW-HPF.
6 Turn MULTI-CONTROL to select NW 3 in
the audio function menu.
Refer to Introduction of audio adjustments on
page 24.
7 Push MULTI-CONTROL left or right to
select the slope of the selected speaker
unit (filter).
Each time MULTI-CONTROL is pushed left or
right, slopes are selected in the following
order:
! High-HPF
6dB/oct.—12dB/oct.—18dB/oct.—
24dB/oct.—30dB/oct.—36dB/oct.
! High-LPF, Mid-LPF, Mid-HPF, Low-LPF,
Low-HPF, SW-LPF and SW-HPF
Pass—6dB/oct.—12dB/oct.—18dB/oct.—
24dB/oct.—30dB/oct.—36dB/oct.
8 Push MULTI-CONTROL up or down to
switch the phase of the selected speaker
unit (filter).
Push MULTI-CONTROL up selects normal
phase and NOR appears in the display. Push
MULTI-CONTROL down selects reverse phase
and REV appears in the display.
# You can adjust the parameters for other
speaker units (filters) in the same way.
9 Press B to cancel the network adjust-
ment mode.
Using the time alignment
The time alignment lets you adjust the dis-
tance between each speaker and the listening
position.
1 Use MULTI-CONTROL to select TA1 in
the audio function menu.
Refer to Introduction of audio adjustments on
page 24.
Audio Adjustments
En
28
Section
03
