DV-380-S
1. CONTRAST OF MISCELLANEOUS PARTS
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
DV-380-S /
WYXTL
DV-380-S /
WYXTL/UR
DV-380-K /
WYXTL/UR
CONTRAST TABLE
DV-380-S/WYXTL, DV-380-S/WYXTL/UR and DV-380-K/WYXTL/UR are constructed the same except for the following:
Part No.
Remarks
PACKING SECTION
P7- 8 Operating Instructions(English,Italian) J2G50321A Not used Not used
P7- 8 Operating Instructions(Russian) Not used J2G50601A J2G50601A
P7- 9 Operating Instructions(German,French) J2G50322A Not used Not used
P7-10 Operating Instructions(Spanish,Duch) J2G50323A Not used Not used
P7-12 Polyethylen Bag JB5KD400 JB5KD200 JB5KD200
P7-15 Gift Box 793WCD1635 793WCDC719 793WCDC732
EXTERIOR SECTION
P9- 5 DVD MECHA ASSY A2F101A650 A2G512A650 A2G512A650
P9-14 Cabinet, Top 702WSB0114 702WSB0114 702WSB0115
P9-24 Sheet, Jack 2 7226310058 7226310058 7226310070
P9-25 Sheet, Jack 3 7226310059 722631A005 722631A007
P9-101 Front, Cabi Assy 7A7010078A 7A7010078A 7A7010095A
Ref.
No.
Mark
