8. EACH SETTING AND ADJUSTMENT
1. At shipment, the unit is adjusted to its best conditions. Normally, it is not necessary to readjust even if an assembly is replaced. If the
adjustment is shifted or if it becomes necessary to readjust because of part replacement, etc., perform the adjustment as described below.
2. Any value changed in Service/Factory mode will be stored in memory as soon as it is changed. Before readjustment, take note of the
original values for reference in case you need to restore the original settings.
3. Use a stable AC power supply.
Y DRIVE Assy No adjustment required
Other assemblies No adjustment required
POWER SUPPLY Unit
DIGITAL Assy
X DRIVE Assy No adjustment required
Refer to “8.3 HOW TO CLEAR HISTORY DATA” .
MAIN Assy (*) Execute section [4-5] AUTO ADJUSTMENT of
6.2 [4] INITIALIZE.
Execute section [4-5] AUTO ADJUSTMENT of
6.2 [4] INITIALIZE.
IO AUDIO Assy
Service Panel Assy
Refer to “8.3 HOW TO CLEAR HISTORY DATA” and
“8.4
ADJUSTMENTS WHEN THE SERVICE
PANEL
ASSY IS REPLACED”.
Writing of backup data is required.
Refer to the “8.2 BACKUP OF THE EEPROM
(DIGITAL ASSY)”.
PANEL SENSOR Assy
No adjustment required
Backup data are automatically copied during the next
power-off.
When any of the following assemblies is replaced
(*) : When replacing the MAIN Assy, be sure to perform the FINAL SETUP.
To Next Page
