Pioneer sc-lx86 Service Manual

2
SC-LX86
1
2 3 4
A
B
C
D
E
F
1
2 3 4
1. CONTRAST OF MISCELLANEOUS PARTS
CONTRAST TABLE
SC-LX86/FXJ, /DLPWXJ, /AXJ5
SC-68/UXJCB, SC-LX86/FXJ, SC-LX86/DLPWXJ and SC-LX86/AXJ5 are constructed the same except for the following:
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5
6 1
4 7 3
R 5 0
1
R 0
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
RN1/4PC F562 x 10
1
5621 5 26 1
Mark No. Symbol and Description
SC-68
/UXJCB
SC-LX86
/FXJ
SC-LX86
/DLPWXJ
SC-LX86
/AXJ5
Remarks
PCB ASSEMBLIES
NSP 1..INTERFACE REG ASSY AWR7150 AWR7168 AWR7168 AWR7168
P79-3 2..IR REG ASSY AWX1173 AWX1324 AWX1324 AWX1324
P79-4 2..B DIODE ASSY AWX1174 AWX1321 AWX1321 AWX1321
P83-4 2..INTERFACE ASSY AWX1172 AWX1313 AWX1313 AWX1313
P83-5 2..A REG BRIDGE ASSY AWX1178 AWX1312 AWX1312 AWX1312
NSP 1..REG BRIDGE ASSY AWR7151 AWR7152 AWR7152 AWR7152
P79-5 2..DISPLAY BRIDGE ASSY AWX1182 AWX1319 AWX1319 AWX1319
P81-9 2..MULTI CH IN ASSY AWX1184 AWX1191
AWX1191 AWX1191
P81-11 2..CONNECT ASSY AWX1187 AWX1325
AWX1325 AWX1325
P83-7 2..REG ASSY AWX1180 AWX1315 AWX1315 AWX1315
P83-9 2..FB-CONNECT ASSY AWX1186 AWX1320 AWX1320 AWX1320
NSP 1..PRIM DISPLAY ASSY AWM8300 AWM8304 AWM8303 AWM8305
P81-1 2..PRIMARY ASSY AWX1142 AWX1146 AWX1145 AWX1147
P85-1 2..DISPLAY ASSY AWX1133 AWX1206 AWX1206 AWX1206
P85-4 2..MIC HP ASSY AWX1149 AWX1299 AWX1299 AWX1299
NSP 1..AUDIO COMPOSITE ASSY AWR7141 AWR7161 AWR7161 AWR7161
P81-2 2..AUDIO ASSY AWX1119 AWX1274 AWX1274 AWX1274
P81-3 2..COMPOSITE ASSY AWX1125 AWX1317 AWX1317 AWX1317
P81-12 1..USB DAC ASSY AWX1097 AWX1257 AWX1257 AWX1257
P81-13 1..DAC HIGH ASSY AWX1104 AWX1253 AWX1253 AWX1253
P81-14 1..COMPONENT ASSY AWX1106 AWX1288 AWX1288 AWX1288
P81-15 1..DIGITAL MAIN ASSY AWX9904 AWX1279 AWX1261 AWX1261
NSP 1..D AMP ASSY AWH7052 AWH7055 AWH7055 AWH7055
P83-1 2..D AMP ASSY AWX1214 AWX1217 AWX1217 AWX1217
NSP 1..IR BUFFER ASSY AWM8307 AWM8314 AWM8314 AWM8314
P83-2 2..IR BUFFER ASSY AWX1170 AWX1323 AWX1323 AWX1323
P85-6 1..FRONT HDMI USB ASSY AWX1111 AWX1291 AWX1291 AWX1291
PACKING SECTION
> P77-4 AC Power Cord ADG7118 ADG7120 ADG7119 ADG7122
P77-8 Quick Start Guide ARH7131 ARH7133 ARH7134 ARH7135

Pioneer sc-lx86 Specifications

General

Receiver type	Surround
Output impedance	6 Ω
Speaker selector	A+B
Audio output channels	9.1 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
AC (power) in	Yes
Remote (IR) input	1
Composite video in	4
Digital audio optical in	2
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	3
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Supported radio bands	AM, FM
Optical drive included	No
Display	-
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital Plus, Dolby Pro Logic, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS-ES, DTS-HD, DTS-HD Master Audio
Apple docking compatibility	iPad, iPhone, iPod
On Screen Display (OSD) languages	DEU, DUT, ENG, ESP, FRE, ITA, RUS
Graphical user interface (GUI) language	English, French, German, Italian, Russian, Spanish
AC input voltage	230-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	370 W
THX-certified	THX Select2 Plus
Cables included	AC
