VSA-AX10, VSX-AX10
2
1. CONTRAST OF MISCELLANEOUS PARTS
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
560
47k
0.5
1
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k RN1/4PC F562 x 10
1
5621
7 CONTRAST OF TABLE
VSX-49TX/KU/CA, VSA-AX10/HY and VSX-AX10/SDLBPW are constructed the same except for the following:
Part No.
Remarks
VSX-49TX VSA-AX10 VSX-AX10
/KU/CA /HY /SDLBPW
PCB ASSEMBLIES
NSP VR & MOTHER ASSY AWM7562 AWM7567 AWM7564
P7- 1 MOTHER ASSY AWX7890 AWX7895 AWX7892
NSP PS & SP ASSY AWK7712 AWK7717 AWM7714
P9- 2 SP (B) ASSY AWX7852 AWX7856 AWX7854
P9- 3 AC PRIMARY ASSY AWX7834 AWX7837 AWX7835
P9- 4 SP (A) ASSY AWX7848 AWX7850 AWX7850
P11- 6 POSISTER (L) ASSY AWX7844 AWX7845 AWX7845
P11- 7 POSISTER (R) ASSY AWX7846 AWX7847 AWX7847
VOLTAGE SEL ASSY Not used Not used AWX7842
No. 1
POSISTER(MT) ASSY Not used AWX8061 AWX8061
No. 2
NSP VIDEO ASSY AWQ7010 AWQ7012 AWQ7012
P9- 6 V-CONVERT ASSY AWX7952 AWX7951 AWX7951
P9- 7 COMPONENT ASSY AWX7953 AWX7955 AWX7955
P9- 9 COMPOSITE ASSY AWX7942 AWX7944 AWX7944
P9-10 A/V I/O ASSY AWX7938 AWX7940 AWX7940
NSP A/D & CONTROL ASSY AWM7558 AWM7560 AWM7659
P9-12 ANALOG IN & A/D ASSY AWX7878 AWX7880 AWX7873
P13- 1 DISPLAY ASSY AWX7864 AWX7866 AWX7866
P9- 1 FM/AM TUNER Module AXQ7237 Not used AXQ7238
PACKING SECTION
P3- 1
AC Power Cord ADG7061 ADG7062 ADG7065
P3- 2
FM Wire Antenna ADH7010
Not used ADH7010
P3- 3 AM Loop Antenna ATB7009 Not used ATB7009
P3- 4
Remote Control Unit AXD7295 AXD7296
AXD7298
P3- 7 Operating Instructions (English) ARB7249 AHA7252 AHA7251
Operating Instructions(German) Not used ARC7345 Not used No. 3
Operating Instructions(French) Not used ARC7346 Not used No. 4
Operating Instructions(Dutch) Not used ARC7348 Not used No. 5
Operating Instructions(Spanish) Not used Not used ARC7344 No. 6
Operating Instructions(Chinese) Not used Not used ARC7343 No. 7
P3- 9 NSP Warranty Card ARY1026 ARY7022 Not used
P3-14 Packing Case AHD8029 AHD8027 AHD8030
Caution 220V Label Not used Not used ARR1003 No. 8
AC Plug Adapter Not used Not used AKX7011 No. 9 Accessories
Ref.
No.
Mark
Symbol and Description
