VSA-AX10, VSX-AX10
30
4. REMOTE CONTROL UNIT [AXD7296&AXD7298]
4.1 CONTRAST OF MISCELLANEOUS PARTS
NOTES : ÷ Parts marked by “ NSP ” are generally unavailable because they are not in our Master Spare Parts List.
÷ The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
÷ Screw adjacent to
∞
mark on the product are used for disassembly.
÷ Reference Nos. indicate the pages and Nos. in the service manual for the base model.
Part No.
Remarks
AXD7295 AXD7296 AXD7298
7 CONTRAST TABLE
AXD7295, AXD7296 and AXD7298 are constructed the same except for the following:
P161- 2 PCB Assy AZC7299 AZC7299 AZC7300
P161-13 Seal A AZA7415 AZA7417 AZA7421
P161-14 Seal B AZA7416 AZA7418 AZA7420
P161-16 Case A AZN7783 AZN7885 AZN7795
P161-17 Name Plate AZA7406 AZA7407 AZA7409
P161-21 Case B AZN7784 102RRC24401R AZN7796
P161-23 Pen Holder AZN7786 AZN7798 AZN7798
P161-26 Battery Cover AZN7785 103RRC14701R AZN7797
P161-32 Slide Knob AZA7347 Not used Not used
P161-36 Key Top A AZA7345 302RRC09901R AZA7363
P161-37 Key Top B AZA7346 302RRC10001R AZA7364
P161-39 Rubber Sheet B AZA7349 Not used AZA7371
P161-40 Rubber Sheet C AZA7411 AZA7414 AZA7411
Ref.
No.
Mark
Symbol and Description
To Next Page
