Page 13
Electric
Gas Drive
COMPONENT IDENTIFICATION
Inlet Filter
Inlet Filter
Compressor
Compressor
Belt Guard
Belt Guard
Pressure Gauge
Pressure
Gauge
Pressure Switch
Tank Drain
Engine
Ball Valve
Tank Drain
Tank
Belt
Tank
Safety Valve-
Not Visible
Safety Valve
Check Valve-
Not Visible
Drive Bushing-
Not Visible
Drive Pulley-
Not Visible
Drive Pulley-
Not Visible
Motor
Drive Belt
Discharge Line
Discharge Line
Unloader
Valve
Ball Valve
