4.Coursecorrectionindicator

5.Coursecorrectiondetails

20.2

Selectingdatapagesusing

touch

Youcanscrollthroughallavailablepagesusingthe

touchscreen.

D12878-1

FromtheDataapplication:

1.T ouchthescreen.

2.Slideyourngerupandletgoofthescreento

gotothenextdatapage.

3.Slideyourngerdownandletgoofthescreento

gotothepreviousdatapage.

294aSeries/cSeries/eSeries
