AppendixESwitchpanelapplication
Vesselcontrolandmonitoringsystems
Whenintegratedwithavesselcontrolandmonitoring
systemyourmultifunctiondisplaycanprovide
monitoringandcontrolsforyourpowercircuits,
breakers,switchesandequipment.
TheSwitchPanelapplicationcanbeusedto:
•Showthestatusofpowercircuits,breakers,
switchesandotherequipment.
•Applypowertoeachcircuitindividually.
•Resettrippedbreakers.
•Controlpowertoindividualequipment.
•Alertuserstoatrippedcircuit.
Vesselcontrolandmonitoringsystem
connection
Themultifunctiondisplaycanconnecttoandcontrol
anEmpirBusNXTvesselcontrolandmonitoring
system.
D12738-1
12 V dc
1
2
4
3
5
1
Raymarinemultifunction
display.
2
EmpirBusNXTDCM(dc
module).
3
SeaTalk
ng
toDeviceNet
adaptorcable.
4
EmpirBusNXTMCU(Master
controlunit).
5
12Vdcsupplyintobackbone.
Note:Ensureyourvesselcontrolandmonitoring
systemhasbeeninstalledinaccordancewiththe
instructionsprovidedwiththesystem.
Switchpanelconguration
Theswitchpanelapplicationmustbecongured.
ACongurationlecanbeobtainedfromthesystem
supplier.
Loadingacongurationle
Theswitchpanelapplicationwillonlybeavailable
whenavalidcongurationlehasbeenloaded.
1.Obtainthecongurationlefromthesystem
supplier.
2.Savethecongurationletotherootdirectoryof
yourmemorycard.
3.Insertthememorycardintothecardreaderon
yourmultifunctiondisplay.
4.FromthehomescreenselectSet-up.
5.SelectSystemSettings.
6.SelectExternalDevices.
7.SelectSwitchPanelSet-up.
8.SelectInstallCongFile.
9.Ifpromptedselectthememorycardslotthat
containsyourcongurationle.
Thelebrowserisopened.
10.Selectthecongurationle.
11.SelectOK.
YoucannowaddtheSwitchpanelapplicationfrom
theCustomizemenuonthehomescreen.
Note:Ifyourmultifunctiondisplayonlyhas1card
slotthenstep9isskipped.
Switchpaneloverview
Theswitchpanelapplicationisusedtomonitorand
controlcompatiblevesselcontrolandmonitoring
systems.Thepagesandpagelayoutsandvessel
schematicsareconguredatinstallationandare
uniqueforeachvessel.Theimagesbeloware
examples.
Example1—Switchpanelmodepage
IfconguredaModepageprovidescontrolsto
switchbetweenpre-conguredmodes.
Intheexampleaboveselectingamodeiconwill
placethesystemintotheselectedmode.
Youcancyclethroughavailablepagestomonitoror
controlswitchesandconguredgroupsofswitches.
Example2—Vesselcontrolspage
454aSeries/cSeries/eSeries

Raymarine e127 Specifications

General

Display Size	12.1 inches
Display Resolution	1280 x 800 pixels
Touchscreen	Yes
Wi-Fi	Yes
Bluetooth	No
Chartplotter	Yes
Radar Compatible	Yes
AIS Compatible	Yes
Display Type	LCD
Waterproof Rating	IPX6
GPS	Yes
Networking	RayNet Ethernet
Sonar	Optional, requires external sonar module
Operating Voltage	12/24 V DC
Fishfinder	Yes, with optional sonar module
Cartography	Navionics, C-MAP
Power Supply	12/24V DC
