3.6Typicalsystems

Theillustrationsbelowshowexamplesofpossiblesystemcongurations.

Formoredetailsoncompatibledevicespleasereferto3.1Systemintegration.

Example:Basicsystem

SeaTalk

/ RayNet

RayNet

SeaTalk

/ RayNet

D12891-1

4 5

6 87

1.Multifunctiondisplay.

2.RMK-9remotekeypad.

3.Radarscanner.

4.ActuatorControlUnit(ACU).

5.AttitudeHeadingReferenceSensor(AHRS).

6.Sonarmodule.

7.GPSreceiver.

8.SeaTalk

pilotcontroller(optional).

Example:Expandedsystem

AUDIO

ANTENNA

NETWORK

POWER

Dxxxxx-x

SeaTalk

/ RayNet

SeaTalk

/ RayNet

SeaTalk

/ RayNet

SeaTalk

/ RayNet

SeaTalk

/ RayNet

DeviceNet

SeaTalk

813

2 3 4

RayNet

1.Radarscanner.

gSSeries
