44 RC435 and RC435i Chartplotters
3. Using the trackpad, set the desired offset value. The distance and
bearing of cursor from vessel is displayed in the Status Bar as BRG and
RNG.
4. Press CLEAR to reset the value to zero and return to the Chart Set Up
menu.
—or—
Press ENTER to confirm the selected offset value.You are returned to
the Chart Set Up menu with POSITION CALIBRATION set to ON. Posi-
tion data is followed by “(c)” to indicate that the calibration offset has
been set.
An offset of 2nm or less is applied to all position data equal to the range
and bearing between the WGS 84 position and the position entered.
Note: Pressing ENTER with a selected offset of more than 2nm gives a
warning message which is cleared on any key press. The Calibration Set
Up mode maintains and the user can either reselect an acceptable offset
or press CLEAR to reset the value to zero and return to the Set Up menu.
4.4 GPS Setup
The GPS set up page provides information for the status of the tracked
navigation satellites plus HDOP and satellite Fix Status. It also provides
the ability to select the SD satellite and to reset the GPS system.
➤ To select GPS Set Up:
1. Press the PAGE key to display the SET UP functions:
2. Use the trackpad to highlight the GPS SET UP function and press
ENTER to display the GPS STATUS screen and soft key. GPS STATUS is
displayed.
D4694_1
