INSTALLATION
1. Seat the RF Modulator vertically :
Plug in the seat plate (included)
on the bottom of the RF Modulator
until The locking tab of the seat
plate clicks in to secure the plate
to the RF Modulator.
2. Seat the RF Modulator horizontally :
2.1 While pulling up the locking tab, remove the seat plate by
pushing out the seat plate.
2.2 Attach the four self-adhesive rubber pads (included) to the
side face of the RF Modulator.
2.3 Lay down the RF Modulator on the side with the rubber
pads.
OPERATION
1. Turn on the TV and set it to either Channel 3 or 4. whichever
is not used for regular broadcasts in your area.
2. Set the RF Modulator’s CHANNEL
3/4 switch to the same channel
you set the TV (3 or 4).
3. Turn on the connected video
source and set OHMS 75/1K on
the RF Modulator to the position
that gives the best picture. The
video ON signal indicator on the
RF Modulator lights when the
modulator is receiving a signal for
an A/V source.
SPECIFICATIONS
Video Carrier Output Level ..............................................69dBμV
RF Output Channels ........................................................... 3 or 4
RF Output Impedance ...................................................75 Ohms
Audio Input Impedance............................................13±3K Ohms
TV to ANT Insertion Loss 50 - 806 MHz ............................... -2dB
DC Adapter ............................................................9 VDC/100mA
Dimensions ........................................... 5
23
/32 x 3 x 1
13
/64 inches
.......................................................................(145 x 75 x 30 mm)
Weight ..................................................................15 oz (.430 kg)
Specications are typical; individual units might vary.
Specications are subject to change and improvement without
notice.
12 Month Limited Warranty
Audiovox Electronics Corporation (the “Company”) warrants to the
original retail purchaser of this product that should this product or any
part thereof, under normal use and conditions, be proven defective
in material or workmanship within 12 months from the date of original
purchase, such defect(s) will be repaired or replaced (at the Company’s
option) without charge for parts and repair labor. To obtain repair or
replacement within the terms of this Warranty, the product along with
any accessories included in the original packaging is to be delivered
with proof of warranty coverage (e.g. dated bill of sale), specication of
defect(s), transportation prepaid, to the Company at the address shown
below. Do not return this product to the Retailer.
This Warranty is not transferable and does not cover product
purchased, serviced or used outside the United States or Canada. The
Warranty does not extend to the elimination of externally generated
static or noise. This Warranty does not apply to costs incurred for
installation, removal or reinstallation of the product, or, if in the
Company’s opinion, the product has been damaged through acts of
nature, alteration, improper installation, mishandling, misuse, neglect,
accident, or the simultaneous use of different battery types (e.g.
alkaline, standard or rechargeable). This Warranty does not cover
damage caused by an AC adapter not provided with the product.
THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS
WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT
PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY’S
LIABILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER
FOR THE PRODUCT.
This Warranty is in lieu of all other express warranties or liabilities. ANY
IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,
SHALL BE LIMITED TO DURATION OF THIS WARRANTY. ANY
ACTION FOR BREACH OF ANY WARRANTY HEREUNDER,
INCLUDING ANY IMPLIED WARRANTY, MUST BE BROUGHT
WITHIN A PERIOD OF 24 MONTHS FROM THE DATE OF ORIGINAL
PURCHASE. IN NO CASE SHALL THE COMPANY BE LIABLE FOR
ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES WHATSOEVER.
No person or representative is authorized to assume for the Company
any liability other than expressed herein in connection with the sale of
this product.
Some states/provinces do not allow limitations on how long an
implied warranty lasts or the exclusion or limitation of incidental or
consequential damage so the above limitations or exclusions may not
apply to you. This Warranty gives you specic legal rights and you may
also have other rights which vary from state/province to state/province.
U.S.A.: Audiovox Electronics Corporation, 150 Marcus Blvd.,
Hauppauge, New York 11788
CANADA: Audiovox Return Center, c/o Genco, 6685 Kennedy Road,
Unit 3, Door 16, Mississauga, Ontario L5T 3A5
© 2007 Audiovox Accessories Corporation
111 Congressional Blvd., Suite 350
Carmel, IN 46032
PCRF900IB Rev0507
Trademark(s) ®Registered Made in China
www.rca.com
CARE
To enjoy your RF Modulator for a long time:
• Keep the modulator dry. If it gets wet, wipe it dry immediately.
• Use and store the modulator only in normal temperature
environments.
• Handle the modulator gently and carefully. Don’t drop it.
• Keep the modulator away from dust and dirt.
• Wipe the modulator with a damp cloth occasionally to keep it
looking new.
Modifying or tampering with the modulator’s internal
components can cause a malfunction and invalidate its warranty
and void your FCC authorization to operate it. If your modulator
is not performing as it should, take it to your local store for
assistance.
