Ducting
DUCTING
FIGURE 5
NOTE:
SOLID BASE PLATE PROVIDED WITH (-)801P
MODELS ONLY.
WHEN SOLID BASE PLATE IS USED . TAPE
AROUND BOTTOM FLANGES OF CABINET
BEFORE THE UNIT IS INSTALLED.
LIFT UP, PULL OUT
1. REMOVE 2 SCREWS, LIFT BASE UP, SLIDE FORWARD TO REMOVE.
2. INSTALLATION IS REVERSE OF REMOVAL.
** VERIFY REAR FLANGE IS SEALED PROPERLY AS SHOWN IN DETAIL.
ST-A1220-10-X0
SOLID BASE FLANGE
F
ITS UNDER
CABINET BOTTOM
FIGURE 6
FIGURE 7
ST-A1220-10
ST-A1220-11
ST-A1220-08
