8
UNIT HEIGHT
37.8” MAX
UNIT WIDTH
33.6” MAX
UNIT LENGTH
33.6” MAX
CONCRETE SLAB
BY OTHERS, TYP.
UNIT WIDTH
33.6” MAX
UNIT LENGTH
33.6”
MAX
UNIT HEIGHT
37.8” MAX
CONCRETE SLAB
BY OTHERS, TYP.
CONTROL
COVER
3
Maximum Rated Wind Pressures:
± 140 psf Lateral, 111 psf Uplift
Hurricane tie-downs are a structural component designed to prevent wind uplift during severe weather, such as hurricanes or severe storms. For further information on tie-downs,
and technical support, contact Raypak at www.raypak.com or call 805-278-5300.
Minimum pad dimensions are 43-1/4”
x 43-1/4” x 4” thick.
Screws to attach brackets to unit are
supplied with the unit.
DO NOT use screws not specified or
provided by manufacturer. Screws
are stainless steel #10 x 3/4”
self-drilling. Each bracket requires 4
screws attached to the unit.
Miami Tech Clip: (0.07”) ASTM A653
Fu=90 KSI Steel (CUTD10) or 0.080”
5052-H32 Aluminum (CUTDA10). Florida
approval FL# 19731.1 or approved equal.
TIE-DOWN SCHEDULE
At-Grade ± 54 psf (0 psf) 4
At-Grade / Rooftop ± 140 psf (111 psf)
8
Installation
Condition
Max. ASD
Wind Pressures
Lateral (Uplift)
1.26 TYP.
32.5 TYP.
1.26 TYP.
1.26 TYP.
# of
Tie-Down
Clips
8.00”- 10.00”
A
B
C
D
(4)-#10
SMS PER
CLIP, TYP.
D
A & B
3000 PSI MIN.
CONCRETE BY
OTHERS, TYP.
ANCHOR PER
SCHEDULE
LOUVER
PANEL,
TYP.
UNIT BASE
PAN
UNIT BASE
PAN
A & C ARE SIMILAR
AND OCCUR ON
OPPOSITE FACES
FRONT CORNER PANEL
C
&
Figure 5. Hurricane Tie Down Instructions – Models: TWPH 4550, 5550, 6550, 6550EHC, 8550, & 8550EHC
