Model
KI-790U:Igniter
CheckPoint
(CircuitBoard)
CN 9
Function
Thepartforsupplyingtheignitionenergytotheburnerbycontinuouslydischargingthe
highvoltage.
FailureEvent
Ignitionisnotgenerated.
E󰘯ects
Operationofproductisstopped.
ErrorCode
Er10,Er11
Diagnostic
① Visualinspection:Connectionand/orbreakageofwire.
② Check:voltagerange
Color/WireNumber
IgnitionTransformer(red):connector④
IgnitionTransformer(red):connector⑩
Inputvoltage Outputcurrent Outputvoltage
AC120V60Hz
6±2mA 15 ±2kV
Chapter2ComponentsDescription
1
2
3
4
5
6
7
8
9
10
11
12
