Paper Feed
D017/D018/D019/D020/D0
84/D085 4-57
SM
Repla
cement
and
Adjustment
4.8.12
DUST COLLECTION BIN
1. Remove:
[A] Front door (L-brackets x2)
[B] Dust collection bin (
x1)
2.
T
ap the dust collection bin above a sheet of paper
, to remove the paper dust.
3.
Use a dry cloth to clean the in
side of the dust collection bin.
