Service Tables
D432/D433 48 SM
4.2.2 SP2-XXX (RAM DATA)
2
Mode No. Function
RAM Read/Write
101
001
Change RAM data for the fax board directly.
"Service RAM Addresses"
Memory Dump
102
001
G3-1 Memory
Dump
Print out RAM data for the fax board.
"Service RAM Addresses"
G3-1 NCU Parameters
103
001 – 023 CC, 01 – 22
NCU parameter settings for the standard G3
board. "NCU Parameters"
4.2.3 SP3-XXX (TEL LINE SETTINGS)
3
Mode No. Function
Service Station
101
001 Fax Number Enter the fax number of the service station.
Serial Number
102
000 Enter the fax unit’s serial number.
PSTN-1 Port Settings
001 Select Line
Select the line type setting for the G3-1 line. If
the machine is installed on a PABX line, select
“PABX”, “PABX(GND)” or “PABX(FLASH)”.
103
002
PSTN Access
Number
Enter the PSTN access number for the
G3-1 line.
