4.Replacement and Adjustment
97
HVP
1. Remove the right cover (Printer models: Right Cover, MF models: Right Cover).
2. Remove the HVP [A].
After removing the HVP, the terminal pins are left in the machine, so be careful not to lose them.
When installing the HVP, make sure that the terminal pins contact the terminals of the HVP straight,
and not at an angle.
Cooling Fan
1. Remove the right cover (Printer models: Right Cover, MF models: Right Cover).
To Next Page
