198
Changing Camera Settings
5
The following five operation sounds are made during camera
operation.
Note ----------------------------------------------------------------------------------------------
If you try to perform an operation that cannot be performed, the beep sound can be heard
regardless of the [Operation Sounds] setting.
1
Display the setup menu.
For the operating procedure, see P.184.
2
Press the " button to select [Operation Sounds] and
press the $ button.
3
Press the !" buttons to select
the desired setting.
4
Press the MENU/OK button.
Note ----------------------------------------------------------------------------------------------
The operation sound setting can be changed. (GP.199)
Changing the Operation Sound
Setting (Operation Sounds)
Start sound : Sound when the camera is turned on.
Shutter : Sound when the shutter release button is pressed.
Focus sound : Sound when the shutter release button is half-pressed and the
camera focuses on the subject.
Beep Sound : Error sound indicating an operation that cannot be performed.
LevelSound : When [Level Setting] is set to [Sound] or [Disp + Snd] (GP.202),
the sound is continually emitted at a set interval when the camera is
level in shooting mode.
Available Settings Description
All
*Default setting
All sounds on
LevelSound Only the level sound will emit.
Shutter Only the shutter sound and level sound will emit.
