11
Reading the Display and Using Keys
This section explains how to read the display and use the selection key for the
initial copy display.
Note
r The copy display is set as the default screen when the machine is turned on.
1. Selection keys
Correspond to items at the bottom line on
the display.
Example: initial copy display
• When the instruction “press [100%]”
appears in this manual, press the left
selection key.
• When the instruction “press [R/E]” ap-
pears in this manual, press the center
selection key.
• When the instruction “press [Auto R/E]”
appears in this manual, press the right
selection key.
2. {Escape} key
Press to cancel an operation or return to
the previous display.
3. {OK} key
Press to set a selected item or entered nu-
meric value.
4. Scroll keys
Press to move the cursor to each direction
one by one.
When {U},{T},{V}, or {W} key appears
in this manual, press the scroll key of the
same direction.
OK
Escape
1
2
3
4
APE026S
To Next Page
