6.3 SYMPTOM TABLES
6.3.1 POST SYMPTOM TABLE
Symptom Action
The main motor, cooling fan, and fuser do
not come on.
p.6-56 "Cover Interlock Switch Service
Check"
POST completes, but the display does not
come on.
p.6-64 "Operator Panel Service Check"
Main motor does not come on.
p.6-60 "Main Motor Service Check"
Fan does not come on.
p.6-55 "Cooling Fan Service Check"
Fuser does not cycle.
p.6-58 "Fuser Service Check"
Fuser does not turn on and off.
p.6-58 "Fuser Service Check"
The paper feed picks and tries to feed
media.
p.6-65 "Paper Feed Service Checks"
 Investigate any displayed codes before proceeding with these symptoms. For example, a
missing toner cartridge will prevent POST from completing.
