Standard Printing
If you send a print job via USB 2.0 while the machine is in Low Power mode or Sleep mode, an
error message might appear when the print job is complete. In this case, check if the document was
printed.
1. Click the WordPad menu button in the upper left corner of the window, and then click
[Print].
2. In the [Select Printer] list, select the printer you want to use.
3. Click [Preferences].
4. Select the [Frequently Used Settings] tab.
5. In the "Job Type:" list, select [Normal Print].
6. In the "Document Size:" list, select the size of the original to be printed.
7. In the "Orientation" area, select [Portrait] or [Landscape] as the orientation of the
original.
8. In the "Paper Type:" list, select the type of paper that is loaded in the paper tray.
9. In the "Input Tray:" list, select the paper tray that contains the paper you want to print
onto.
If you select [Auto Tray Select] in the "Input Tray:" list, the source tray is automatically selected
according to the paper size and type specified.
10. If you want to print multiple copies, specify a number of sets in the "Copies:" box.
11. Click [OK].
12. Start printing from the application's [Print] dialog box.
4. Print
72

Table of Contents

Other manuals for Ricoh MP W6700

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh MP W6700 and is the answer not in the manual?

Ricoh MP W6700 Specifications

General IconGeneral
Warm-up time120 seconds
Power source220 - 240 V, 50/60 Hz
Print Speed6.7 ppm (A1 horizontal)
Resolution600 dpi
Maximum Print Width914 mm
Media TypesPlain paper
ConnectivityUSB 2.0, Ethernet 10/100/1000 Base-T
Dimensions1, 250 x 755 x 1, 200 mm
Original Size24 inches
Memory512 MB
Paper weight52 - 110 g/m²
Supported paper sizesA4 - A0
Paper input capacity2 rolls
