1104: Image Position Gap
To adjust the position manually, use 1104 [Image Position Gap].
Image Position: Side 1/Image Position: Side 2
Adjust the vertical/horizontal position of the image to be printed on side 1/2 of the paper.
If J33 occurs, adjust the values by 1 mm toward the [+] side to widen the margins. Adjust the value
carefully for wider margin improves the separation of paper in the fusing unit, but may degrade the
deviation in image position.
Setting Item Max. Value Min. Value Step Unit
01: Across Feed/02: With Feed/03:
Across Feed/04: With Feed
3 -3 0.01 mm
Image Magnification: Side 1/Image Magnification: Side 2
Adjust the vertical/horizontal image scaling on the side 1/2 of the paper according to the paper
expansion or shrinkage.
Setting Item Max. Value Min. Value Step Unit
05: Across Feed/07: Across Feed 0.5 -0.5 0.001 %
06: With Feed/08: With Feed 0.025
Trapezoidal Distortion: Side 1/Trapezoidal Distortion: Side 2
Adjust the perpendicularity (image magnification of trailing edge with across feed direction) of side
1/2.
Setting Item Max. Value Min. Value Step Unit
09: Operator Side/10: Opposite Side of
Operator/11: Operator Side/12:
Opposite Side of Operator
0.34 -0.34 0.001 %
4. Adjustment Setting Items for a Custom Paper
160
