5. Adjustment Settings for Operators
How to Use the "Operator Adjust." Screen
This section explains how to operate the "Operator Adjust." screen.
1. Searches for a setting item to be adjusted.
2. Close the hierarchy ( )
Press this to hide the adjustment items that are displayed in hierarchy layers, and display the root groups of the
adjustment items.
3. [Output to File]
Press this to save the setting values of the item you adjusted to a file in the CSV format.
4. [Adjustment Print]
Navigates to the adjustment print screen. On the screen, you can check the changes made to the setting, and
other information.
5. Setting Screen
Specify or modify the adjustment item.
6. Displays the list of groups
Select the group to display the adjustment setting that belongs to the group, and select the adjustment setting
to display its current setting. When you select the adjustment setting whose value can be specified or modified,
the setting screen appears to the right.
• All items in Operator Adjust. appear regardless of which of the machine's optional components are
installed. If you change the settings of options that are not installed, the changes will have no effect.
181
