Paper Bail Motor
1.
Paper output cover (
page 15
).
2.
Paper bail motor [A] (
×2,
×1).
Paper Output Guide Plate Motor
1.
Control board (
page 16
).
2.
Paper output guide plate motor [A] (
×2,
×1,
×1).
Strike Roller Motor
1.
Paper output cover (
page 15
).
Motors
35
36
38
