2. Remove the clip [A].
3. Lift off the door [B] from its bottom post.
Proof Tray
1. Proof tray [A] ( x2)
Corner Strip Cover
Preparation
• Front door page 19)
• Proof tray page 20)
1. Remove the top and bottom screws [A], [B] ( x2).
2. Disconnect the tabs at the top and bottom.
1. Replacement and Adjustment
20
