9
USING THE PROXIMITY TAG
(1P model only)
The proximity tag is
correctly used by
applying it within a 2
cm (two centimeter)
distance from the
key, as shown at right.
TECHNICAL SPECIFICATION
Electrical
Battery Type CR123, 3V lithium battery (x 2)
Current Consumption Stand by current 10µA,
Max current 100 mA
Frequency 868.65 MHz
Modulation Type 00K
Typical Battery Life 3 years
Physical
Dimension (HxWxD) 100 mm x 45 mm x 25 mm
(3.9 x 1.8 x .98 inches)
Weight (Including batteries) 0.157 kg
Environmental
RF Immunity According to EN50130-4
Operating temperature -40°C to 70°C (-40°F to 159°F)
Storage temperature -40°C to 70°C (-40°F to 159°F)
IP Rating 65 (1P model only)
Compliance Statement
EN50131-1, EN50131-3 Grade 2
EN50130-5 Environmental class IV
EN50131-6 Type C
