Publication IASIMP-QS003B-EN-P - October 2009 161
Chapter
12
Create a PanelView Plus Application
Introduction
In chapter 9, you used ladder logic in RSLogix 5000 programming software to create a push
button that controlled an status indicator on a digital output module. In this chapter, you use
FactoryTalk View Machine Edition software to create an application with a push button and a
multistate indicator that uses that ladder logic. You also transfer the application to the
PanelView Plus terminal to test communication with the controller.
Before You Begin
• Prepare the CompactLogix hardware (Chapter 1).
• Prepare the computer (Chapter 2
).
• Prepare the PanelView Plus terminal (Chapter 5
).
• Cofigure your EtherNet/IP network (Chapter 7
).
• Create a project in RSLogix 5000 programming software (Chapter 9
).
What You Need
• FactoryTalk View for Machine Edition software
