Roland Camm-1 CX-24/12 User Manual

45
9 Display Menu Descriptions
Stored in Memory
Factry Default
Selection Choices
Description
Yes
LIGHT
LIGHT, HEAVY
Sets the weight of the material. If material feed is not performed smoothly,
set this switch to [HEAVY].
When set to [HEAVY], the upper limit for the cutting speed is set at 10 cm/
sec., and the force used to move the material and the blade increases. This
should normally be set to [LIGHT].
WEIGHT| <LIGHT>
WEIGHT
Stored in Memory
Factry Default
Selection Choices
Description
Yes
USER1
USER1 to 8
This calls up the setting values stored using [RESTORE].
CALL| <USER1>
CALL
Stored in Memory
Factry Default
Selection Choices
Description
Yes
USER1
USER1 to 8
This stores the setting values for the respective menu items that are now
being used.
The menu items that you can register are as follows.
FORCE, SPEED, OFFSET, and WEIGHT
You can call up stored setting by using [CALL].
RESTORE| <USER1>
RESTORE
Stored in Memory
Factry Default
Selection Choices
Description
Yes
AUTO
AUTO, PARA, SERIAL
This specifies the type of interface for connection to the computer.
AUTO
This selects the port automatically. The communication parameters for a
serial connection are set according to the settings made on the CX-24/12.
If the interface is not recognized correctly when set to AUTO, use the menu
to choose the type of interface you're using.
PARA (PARALLEL)
Choose this when connected to the computer using a parallel cable.
SERIAL
Choose this when connected to the computer using a serial cable.
I/O | <AUTO>
I/O
