69
Parameter List
FLITER ENV
Parameter Value Explanation
Env Depth -63–+63
Species the depth of the Filter envelope.
Higher settings increase the change
produced by the Filter envelope. Negative (-)
value will invert the shape of the envelope.
TVF Env Fine Depth -63–+63 Finely adjusts the depth of the lter envelope.
Velocity Curve FIXED, 1–7
Selects one of the following seven types of
curve by which keyboard playing dynamics
aect the depth of the lter envelope.
If you don’t want keyboard playing dynamics
to aect the lter envelope depth, specify
“FIXED.”
Velocity Sens -100–+100
Specify this if you want keyboard playing
dynamics to aect the lter envelope depth.
Specify a positive “+” value if you want the
lter envelope to apply more deeply as you
play more strongly, or a negative “-” value if
you want it to apply less deeply.
T1 Velocity Sens -100–+100
Specify this if you want keyboard playing
dynamics to aect Time 1 of the lter
envelope. If you want Time 1 to be speeded
up for strongly played notes, set this
parameter to a positive “+” value. If you want
it to be slowed down, set this to a negative “-”
value.
T4 Velocity Sens -100–+100
Specify this if you want key release velocity
to aect Time 4 of the lter envelope. If you
want Time 4 to be speeded up for quickly
released notes, set this parameter to a
positive (+) value. If you want it to be slowed
down, set this to a negative (-) value.
Time Keyfollow -100–+100
Specify this if you want the lter envelope
times (Time 2–Time 4) to vary depending on
the keyboard position you play. Relative to
the lter envelope times at the C4 key (middle
C), positive “+” values shorten the times for
notes played in the region above C4, and
negative “-” values lengthen the times. Higher
values will produce greater change.
0
C4C3C2C1 C5 C6 C7
-50
-100
+50
+100
Key
FENV LFO Trigger
Switch
OFF, ON
If this is ON, the lter envelope is cyclically
retriggered by LFO1.
* This is eective when Envelope Mode is
SUSTAIN.
T1/Attack,
T2,
T3/Decay,
T4/Release
0–1023
Specify the lter envelope times (Time 1–Time
4). Higher settings will lengthen the time until
the next cuto frequency level is reached. (For
example, Time 2 is the time over which Level 1 will
change to Level 2.)
* If ADSR Envelope Switch is ON, the Time 2 has
no eect.
Note on
T: Time L: Level
L3
L0
L2L1 L4
L0,
L1,
L2,
L3/Sustain,
L4
0–1023
Specify the lter envelope levels (Level 0–
Level 4).
Specify the amount of cuto frequency
change at each point relative to the reference
cuto frequency (the cuto frequency value
specied in the Filter screen).
* If ADSR Envelope Switch is ON, only Level 3
(Sustain) has an eect.
AMP
Parameter Value Explanation
Level 0–127
Sets the volume of the partial. This setting
is useful primarily for adjusting the volume
balance between partials.
Velocity Curve FIXED, 1–7
Selects one of the following seven curves that
determine how keyboard dynamics will aect
the volume. Set this to “FIXED” if you don’t
want the volume of the partial to be aected
by the keyboard velocity.
Velocity Sens -100–+100
Set this when you want the volume of the
partial to change depending on the force
with which you press the keys.
Set this to a positive (+) value to have the
changes in partial volume increase the more
forcefully the keys are played; to make the
partial play more softly as you play harder, set
this to a negative (-) value.
Bias Level -100–+100
Adjusts the angle of the volume change that
will occur in the selected Bias Direction.
Higher values will produce greater change.
Negative (-) values will invert the change
direction.
Bias Position 0–127
Species the key relative to which the volume
will be modied. A setting of 64 is the C4 key
(middle C).
Bias Direction
Selects the direction in which change will occur starting from the
Bias Position.
LOWER
The volume will be modied for the keyboard
area below the Bias Point.
UPPER
The volume will be modied for the keyboard
area above the Bias Point.
LOWER&UPPER
The volume will be modied symmetrically
toward the left and right of the Bias Point.
ALL
The volume changes linearly with the bias
point at the center.
Pan L64–63R
Sets the pan of the partial. “L64” is far left, “0”
is center, and “63R” is far right.
Pan Keyfollow -100–+100
Use this parameter if you want key position
to aect panning. Positive (+) value will cause
notes higher than C4 key (center C) to be
panned increasingly further toward the right,
and negative (-) value will cause notes higher
than C4 key (center C) to be panned toward
the left. Higher values will produce greater
change.
C4C3C2C1 C5 C6 C7
0
+50
+100
-50
-100
L
Key
Random Pan Depth 0–63
Use this parameter when you want the stereo
location to change randomly each time you
press a key.
Higher values will produce a greater amount
of change.
Alternate Pan Depth L63–63R
This setting causes panning to be alternated
between left and right each time a key
is pressed. Higher values will produce a
greater amount of change. “L” or “R” settings
will reverse the order in which the pan will
alternate between left and right.
For example if two partials are set to “L” and
“R” respectively, the panning of the two tones
will alternate each time they are played.
Vibrato Level Sens -100–+100
Species how the program’s Modify Vib
Depth aects the Amp Depth of LFO1.
Stereo Width 0–100
Adjusts the amount of width when
outputting in stereo. This has no eect when
outputting in mono.
To Next Page
