Roland INTEGRA-7 User Manual

03 Using the Internal Sounds
About the INTEGRA-7’s screen
When you turn on the INTEGRA-7, the top screen will appear. You can choose the type of top screen (p. 48).
The “*” indicates an edit
The “!” indicates use of
sound that’s not loaded
Part number
Tone bank
Part level meter
Solo on/o of the current
part (p. 30)
Mute on/o of each part
(p. 30)
Tone number and tone
name of the current part
Part number
External audio input level
Tone type
Playing SuperNATURAL tones
1. Press the [SuperNATURAL] button.
The tone of the selected part will change to a SuperNATURAL
tone.
The display will show the SuperNATURAL tone list.
2. Use the cursor buttons to change the type or the bank.
3. Use the value dial to select a tone.
4. Press the [ENTER] button.
The part’s tone will be selected.
Connecting a MIDI keyboard and performing
Connection example
OUTPUT A (MIX)
OUTPUT
To powered speakers
or amp
MIDI IN
Keyboard
INTEGRA-7
* Depending on the settings of the connected MIDI keyboard, note messages played on the keyboard might be transmitted on several
channels. Make settings on your MIDI keyboard so that the MIDI output is appropriate.
Playing PCM tones
1. Press the [PCM] button.
The tone of the selected part will change to a PCM tone.
The display will show the PCM tone list.
2. Use the cursor buttons to change the type or the bank.
3. Use the value dial to select a tone.
4. Press the [ENTER] button.
The part’s tone will be selected.
MEMO
Tone Preview function
By pressing the [VOLUME] knob you can audition the tone of the selected part.
12

Roland INTEGRA-7 Specifications

General

Audio (L/R) in	2
USB connector type	USB Type-A
Audio (L/R) out	5
Digital audio coaxial out	1
Product color	Gray
Sound effects	Chorus, Reverberation
Built-in speaker(s)	No
Chorus effects quantity	3
Reverberation effects quantity	6
MIDI in	Yes
6.35 mm (1⁄4-inch) input	4
6.35 mm (1⁄4-inch) output	8
Display type	LCD
Power source type	AC

Weight and Dimensions

Depth	262 mm
Width	481 mm
Height	89 mm
Weight	3900 g
