Roland RD-700 Service Note

8
Jun. 2001 RD-700
PARTS LIST
fig.part1e
MB -> MAIN BAORD ASSY, SRX -> SRX BASE BOARD ASSY, PLB ->PANEL L BOARD ASSY, PRB -> PANEL R BOARD ASSY, JB -> JACK BOARD ASSY,
IB -> INLET BOARD ASSY
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
SAFETY PRECAUTIONS:
The parts marked have safety-related characteristics. Use only listed parts for replacement.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp Key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in delayed or even
undelivered replacement.
NOTE: The parts marked # are new. (initial parts)
CASING Q’ty
# 02560712 BENDER PANEL 1
# 02564890 BLIND 1
# 02564945 BOTTOM BOARD 1
# 02564912 DISPLAY COVER 1
# 02560701 END BLOCK 1
22225371 ESCUTCHEON 2P D S-ESCT SX2H BLK L=30 2
# 02564923 EXP COVER 1
01236834 POT. DUST COVER A 1
# 02560689 SIDE PANEL L 1
# 02560690 SIDE PANEL R 1
22225373 SVR COVER D S-ESCT SX1H BLK L=30 222-373 1
# 02455467 TOP PANEL 1
CHASSIS
00128089 END BLOCK HOLDER 1
# 02564878 SIDE HOLDER L 1
# 02564889 SIDE HOLDER R 1
KNOB, BUTTON
01125890 D S-KEYTOP SD1H-A CLR 4
22485295 D S-KNOB S BLK/LCG 5
01234090 D T-KEYTOP MX4B BLK 1
01783934 N S-KEYTOP MD2H 1
01783956 N S-KEYTOP MD4H 2
22480260 P R-KNOB MF BLK/LCG 6
02011412 Y S-KEYTOP SD1H BLK 17
02011456 Y S-KEYTOP SX1H BLK 1
# 02670234 Y S-KEYTOP SX1H LCG 1
SWITCH
01784401 SDDJE1-A-2 10A/250VAC SEESAW SWITCH 1
01783801 SKHJFF WITH LED AMBER TACT SWITCH SW005 on PLB 1
01343478 SKQNAE TACT SWITCH SW013,SW002,SW001,SW008,SW010,SW012,SW014,
SW011 on PLB.SW116,SW105,SW106,SW107,SW108,
SW109,SW111,SW127,SW112,SW104,SW115,SW121,
SW117,SW118,SW119,SW120,SW103,SW122,SW124,
SW125,SW126,SW113,SW102,SW101,SW123 on PRB
8+25
01232212 SKHJGR (GREEN) TACT SWITCH WITH LED SW004 on PLB 1
01232201 SKHJGS (ORANGE) TACT SWITCH WITH LED SW003,SW006 on PLB 2
JACK, EXT TERMINAL
13449261 HLJ4306-01-3070 6.5MM JACK JK403,JK404,JK405 on JB 3
13449284 HLJ7001-01-3010 6.5MM JACK JK303,JK302 on JB 2
13449169 YKB21-5078 6.5MM JACK JK301 on JB 1
13429274 YKF51-5041 MIDI CONNECTOR JK401 on JB 1
DISPLAY UNIT
# 02565034 F-51320GNY-LY-AA LCD UNIT 1
NOTE: Replacement F-51320GNY-LY-AA should be made on a unit base.
POWER SUPPLY UNIT
01785823 A1DU2L3B034 SWITCHING REGULATOR 1
NOTE: Replacement A1DU2L3B034 should be made on a unit base.

Roland RD-700 Specifications

General

Polyphony	128 voices
Effects	Reverb, Chorus, EQ
Connectivity	Headphones
Power Supply	AC 117 V
Keyboard	88 keys (PHA II Ivory Feel Keyboard)
