63
Using the RD-700SX As a Master Keyboard
To switch the tones of an external MIDI device, the program number and the MSB/
LSB of the Bank Select message are entered as numerical values on the RD-700SX.
fig.Q3-06p
1
Press [EXTERNAL/INTERNAL], getting the indicator to light.
The EXTERNAL screen appears.
If “MSB” doesn’t appear on screen, press CURSOR [ ] several times to display the
following screen.
fig.Q3-07g
2
Press CURSOR [ ]/[ ]/[ ]/[ ] to move the cursor, then press
[INC]/[DEC] to set the MSB, LSB, and PC for each part.
Pressing [INC] and [DEC] simultaneously switches the settings value to “--- (OFF).”
When this setting is “--- (OFF),” bank select messages will not be transmitted.
Selecting Sounds on an External MIDI Device
Parameter
Tx Settings
OUT (MIDI OUT Port)
--- ALL, 1, 2, USB
Ch (MIDI Channel) --- 1–16
MSB (Bank Select MSB) CC 00 0–127, --- (OFF)
LSB (Bank Select LSB) CC 32 0–127, --- (OFF)
PC (Program Change) Program Change 0–127, --- (OFF)
1
2
When Rec Mode is set to ON in
the Utility Rec Setting in Edit
mode, the EXTERNAL screen
as shown to the left is not
displayed. Set Rec Mode to
OFF when setting the MIDI
Transmit channel (p. 101).
If the external MIDI sound
generator transmits a Program
number or a Bank number for
which no Tone has been
assigned, an alternate Tone
may be selected, or in some
cases, there may be no sound
played. If you do not want to
transmit the Program number
or Bank Select, use the
procedure described left to set
the PC/MSB/LSB to “---
(OFF).”
