VA-3
Jan, 2001
7
J3919108 RESISTOR ARRAY EXB-V8V-103-JV RA3, 4, 5,11, 14, 16, 32, 35, 46 on MB 9
J3919109 RESISTOR ARRAY EXB-V8V-470-JV RA17=>26 on MB 10
13819132RI UNINFL.RES. 100 OHM 0.6W 5% R2=>9 on CB 8
13819131RI UNINFL.RES. 10 OHM 0.6W 5% R2 on PAB / R82 on CDB 2
J3809153 UNINFL.RESISTOR 0.22 0.6W 5% R1 on LCD 1
J3809134 UNINFL.RES. 27 OHM 0.6W 5% R10 on CB 1
J3809150 UNINFL.RES. 33 OHM 1/4W 5% R1=>4 on PB 4
13819302RI CARBON RESISTOR 150 OHM 1W 10% R7, 8 on PAB 2
J3809152 OXIDE RESISTOR 0.22 OHM 1W 5% R39 on JB 1
J3809139 OXIDE RESISTOR 2.2 OHM 3W R1, 11 on PAB 2
01783623 RESIST. 2010 10 OHM1/2W 5% R89 on JB 1
POTENTIOMETER
00459901 ROT. POT. 10KB 14K 1230 VR1 on VB 1
13299206 TRIMMER POT. EVND 8AA03B24 VR1 on MB 1
J3219101 ROT.POT. 5KB 90° - MONO VR1 on JB 1
13279988 ROT.POT. RK09K12A0A2AAc VR2 on JB 1
CAPACITOR
15359776 POL.COND. 0805 390P 5% C48 on JB 1
J3629144 ELCTRL.COND. 470UF 16V AX C3 on CB 1
13639154 ELECTRL.COND.-V 1000UF 16V C48 on CDB 1
J3629122 ELECTRL.COND.-V 1000UF 25V C46 on JB 1
13639661RI ELECTRL.COND.-V 2200UF 25V C14 on PAB 1
13649662RI ELECTRL.COND.-V 3300UF 25V C12 on PAB 1
J3629117 ELECTRL.COND.-V 4700UF 25V C13 on PAB 1
J3629103 ELECTRL.COND. 100U 25V P5 C17, 18 on PAB / C49, 57, 79, 80, 84, 85 on JB /
C69, 70 on MB / C4 on LCD 11
J3629147 ELECTR. COND. 220U 25V P.5 C10 on PAB 1
J3629135 ELECTRL. COND. 470U 35V P5 C45 on JB / C2 on IB 2
J3629132 ELECTRL.COND. 100U 50V P5 C2, 4 on LCD 2
J3629104 ELECTRL.COND. 10U 50V P5 C3, 11 on PAB / C25, 26, 74, 77, 117 on JB 7
J3629154 ELECTR.COND. 3.3U 50V P.5 C113 on JB 1
J3629105 ELECTRL.COND. 47U 50V P5 C8 on PAB / C6, 56, 114, 115 on JB /
C1, 7, 8, 11 on LCD 9
J3629106 ELECTRL.COND. 4.7U 63V P5 C3 on LCD / C108, 109 on JB 3
J5369103 ELECTR. COND. RV2 100U 16V (SMD) C71 on MB 1
J5369104 ELECTR. COND. RV2 10U 16V (SMD) C2, 38 on MB 2
# J5369107 ELECTR. COND. RV 330U 16V (SMD) C232 on MB 1
J5369105 ELECTR. COND. RV3 33U 16V (SMD) C1, 93, 96, 147, 148, 175, 176, 202, 230 on MB 9
J5369102 ELECTR.COND. RV2 47U 16V SMD C201, 188 on MB 2
J3629143 ELECTR. COND. 10U 16V H.7 C44, 45 on CDB 2
J3629137 ELECTR. COND. 33U 16V H.7 C2, 5 on CB 2
J3629142 ELECTR. COND. 1U 63V H.7 C43 on CDB 1
13649103J0 UNPOL.COND. 10U 16 P5 C12, 14, 16, 18, 21, 22 on JB 6
00239412 POLYEST.COND. AMZV0050J 122 0200 C61, 78 on JB 2
00239390 POLYEST.COND. AMZV0050J 561 0200 C81, 86 on JB 2
INDUCTOR, COIL, FILTER
<<EMI>> 12449382RI NOISE SUP. PLT1-R53C L1 on PAB 1
<<EMI>> 12449370 NOISE SUP. SBT-0160W L2, 3 on JB 2
<<EMI>> 12449326 NOISE SUP. SBT-0460 L4 on JB 1
<<EMI>> J2399101 NOISE SUP. BL03RN2-R62T2 L1=>6 on PB 6
<<EMI>> 13529187 NOISE SUP. ELKTR391CA FL2=>6 on CB 5
<<EMI>> J2399103 CHIP NOISE SUP. ELKS471FA FL2=>4, 6 on MB / FL 1, 2, 4, 5 on JB 8
<<EMI>> J2399104 CHIP NOISE SUP. EXCCL4532U1 L1,7,8,9 on JB / L4=>9,18,39=>42,51,53,55 on MB 18
<<EMI>> 00452034 CHIP NOISE SUP. BK2125HM102 L21=>38 on MB 18
<<EMI>> 12449355 NOISE SUP. FBR07H850TB00 L5, 12 on JB 2
<<EMI>> 12449449 INDUCTOR RCH-875-151K L11 on JB / L1 on LCD 2
CRYSTAL, RESONATOR
00894023 X-TAL 20 MHZ MA-406 X1 on MB 1
00894034 X-TAL 16 MHZ MA-406 X2 on MB 1
ENCODER
01013223 ENCODER EVQ-VEM F01-24B ENC1 on CB 1
CONNECTOR
13419677RI 16P FEM. CONNECTOR AMP 1.27 CN16, 29 on MB / CN4 on RCB / CN3 on LCB 5
13369689RI 20P FEM. CONNECTOR AMP 1.27 CN6 on JB / CN1, 9, 15, 24 on MB 5
J3429122 14P FEM. CONNECTOR AMP 1.27 CN4 on MB / CN1 on CB 2
13379151 14P FEMALE CONN. 1.25 R CN9 on LCD 1
J3429125 FEMALE CONNECTOR 52043-0410 CN7 on CB 1
13369688RI 4P MALE CONN. P 2.5 M CN1, 6, 7 on PAB / CN2 on JB / CN1 on IB 6
J3439106 9P MALE CONNECTOR P 2.5 M CN3 on PAB / CN3 on JB 2
J3439109 5P MALE CONNECTOR P 2.5 M CN2 on PAB 1
J3439121 6P MALE CONN. P.2 M CN1 on JB / CN4 on CB 2
J3439143 34P MALE CONN. P. 1.27 M CN17 on MB 1
J3439123 6P MALE CONN. P. 2 M 90° CN5 on VB 1
J3439142 3P MALE CONNECTOR P/2.5 M CN5 on PA 1
J3429120 3P MALE CONNECTOR P.2 M CN4 on JB / CN4 on LCD 2
J3439148 7P MALE CONNECTOR P.2 M CN4 on PAB/CN21 on MB/CN15 on CDB/CN1 on PB 4
# J3439178 4P MALE CONNECTOR IL-G-4P-S3T2-E CN2 on IB 1
WIRING, CABLE
K3468205 4P CABLE (48/90) W(4PC) For details refer to WIRING DIAGRAM on page 5 1
# K3468221 4P CABLE (66) -2C D/R 1
# K3468222 4P CABLE (22) R/2V 2C D/D 1
K3468171 9P CABLE (22) -2C D/R 1
# K3468223 14P FLAT CABLE (16) -2C D/R 1
K3468189 16 FLAT CABLE (16) -2C 1
K3468185 20P CABLE ASSY (24) -2C 1
# K3468224 20P CABLE (18) -2C D/R FLAT 1
K3468203 34P FLAT CABLE (12) -2C 1
# J3439177 AWG18 CBL (30) GREEN + FASTON (2) 1
7695008001 16P FLAT CABLE (26) -2C 1
# 7770712000 4P CABLE ASSY (18) FLAT 1
7699415000 3P CABLE ASSY (44) -2C P.2 1
7712021000 2P COAXIAL CBL ASSY (44) -2C P.2 D/R 1
7712022000 2P SHIELDED CBL ASSY (12) -2C D/R 1
# 7770713000 3-CABLE ASSY (44) 2G/1R -2C (W4P+3P) 1
7699516000 7P CABLE ASSY (20) -2C P.2 1
7712023000 7P CABLE ASSY (72) -2C P.2 D/R 1
SCREW
J2289122 SCREW 2.2X6 TC TC BRUN 2
J2289116 SELF TAP.SCREW 3.5X13 TC TC 4
J2289125 SCREW 2.9X10 TC TC PR TROP 86
J2289130 SCREW 2.9X13 TC TC PR TROP 35
J2289160 SELF TAP.SCREW 2.9X13 TCTCPR BR 1
J2289118 SCREW 2.9X16 TC TC PR BRUN 3
J2289108 SELF LOCK.SCREW M3X10 TCTC H.6 6
J2289147 SELF LOCK.SCREW M3X12 TCTC H.6 2
J2289111 SELF LOCK.SCREW M3X4 TCTC H. 6 4
J2289193 SELF LOCK.SCREW M3X6 TC TC H.6 18
J2289149 SCREW 3X20 TC TFR H.7 4
J2289186 SCREW 3.5X16 TCPR TFR H.8 BRUN 30
J2289113 NUT 3MA H.3 4
PACKING
# K2638249 RIGHT POLYST. END SIDE VA-3 1
# K2638250 LEFT POLYST. END SIDE VA-3 1
K2678102 POLYETH. ENVELOPE 25X45 1
K2678105 CARTENE ENVELOPE HD 140X57 1
K2678106 POLYETH.ENVELOPE 4OX55 1
# K2618239 OUTER PACKING VA-3 1
MISCELLANEOUS
J2139102 TOOTHED WASHER I/D 3 4
22165134 BRASS BUSHING 4
K2168107 SPACER F/LED H.8.8 HEX. 31
00453223 LED SPACER H. 7 E.D. 5 2
J2359101 SPACER 3M ART. SJ5012 5
22265242 RUBBER GUIDE BUSHING 4
J2369106 WIRE HOLDER CLAMPING RN04 2
J2159102 PLASTIC RIVET SR3055 2
K2288106 SPEAKER GASKET 108/120 TH.2 2
02126390 TOUCH SCREEN SENSOR EMU601A2MA16 1
K224815201 BLACK ANTIDUST PL45N LCD VA-7/VA-5 1
1342982301 POWER SUPPLY SOCKET HOLDER N°2 1
22365708 HOLDER F/POWER SUPPLY CBL 1
01343089 D-BEAM CONTROLLER ESCT BLK 1
ACCESSORIES
# K2378120 USER PROGRAM/DEMO/STYLES DISK N°1 VA-3 1
# K2378121 USER PROGRAM/DEMO/STYLES DISK N°2 VA-3 1
K2128126 BLACK MUSIC REST VA-7/VA-5 1
K6018109 MIDI GUIDE 1
# K6018411 OWNER'S MANUAL (ENGLISH) VA-3 1
# K6018415 MIDI IMPLEMENTATION MANUAL VA-3 1
2244861102 POWER ADAPTOR ACJ 230V 12V 2A SA (230V) 1
2244861401 POWER ADAPTOR ACJ 240VA 12V 2A SA (240VA) 1
2244861201 POWER ADAPTOR ACJ 120V 12V 1.75A SA (117V) 1
2244861002 POWER ADAPTOR ACJ 230VE 12V 2A SA (230VE) 1
2244861301 POWER ADAPTOR ACJ 100T 12V 2A SA (100V) 1
