Ryobi ERP6582 User Manual

1. Dust direction knob
2. Depth adjustment knob/auxiliary handle
3. Dust port
4. Trigger switch
5. Main handle
6. Lock-off button
7. Live tool indicator
8. Collar
DESCRIPTION
Fig. 4
2
6
4
Fig. 3
1
Fig. 2Fig. 1
5
5
4
4
1
6
1
2
2
3
3
8
7
7
9
9. Dust bag
10. Front shoe
11. Blade
12. Knob bolt
13. Bracket
14. Edge guide
15. Knob nut
16. Carriage head bolt
17. Blade holder
18. Belt cover
19. Belt
20. Small pulley
21. Large pulley
22. Tool stand

Ryobi ERP6582 Specifications

General

Brand	Ryobi
Model	ERP6582
Category	Planer
Language	English
