Ryobi RPT400 User Manual

5
ENGLISH
SPECIFICATIONS
Voltage :...........................................................220~240 V
Power : ................................................................... 400 W
Cutting Capacity : ................................................16.5 mm
Blade Length : ......................................................400 mm
Blade Speed : .................................................. 1700 min
-1
Weight : ...................................................................4,1 kg
Measured Sound Power Level : ......................... 87 dB(A)
Guaranteed Sound Power Level : ...................... 97 dB(A)
Vibration : ...........................................................1,36 m/s²
DESCRIPTION
Fig.1
1. Blade Cover
2. Blades
3. Four-Position Pivoting Head
4. Telescopic Pole
5. Lock-Off Button
6. Rear Handle
7. Switch Trigger
8. Cord Retainer
Fig.2
9. Packaged Tool
10. Cord
11. Threaded Collar
12. Trimmer Head
13. Lock Hole
14. Egg-Shaped Pole
15. Threaded Base
Fig.4
16. Pivot Button
17. Notches
ASSEMBLY
UNPACKING
This product requires assembly.
n Carefully remove the product and any accessories from
the box. Make sure that all items listed in the packing
list are included.
n Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
n Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product.
n If any parts are damaged or missing, please contact
Customer Service on: (AUS) 1300 557 492 (NZ) 9573
0230
PACKING LIST
Pole Hedge Trimmer
Operator’s Manual
WARNING:
If any parts are damaged or missing, do not
operate this product until the parts are replaced.
Failure to heed this warning could result in
serious personal injury.
WARNING:
Do not attempt to modify this product or create
accessories not recommended for use with this
product. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to possible serious personal injury.
WARNING:
Do not connect to power supply until assembly is
complete. Failure to comply could result in
accidental starting and possible serious personal
injury.
ASSEMBLING THE TOOL
See Figure 2.
Before using the pole hedge trimmer, a one-time assem-
bly is required.
n The telescopic pole and trimmer head come
unassembled. Remove from packaging and extend
the telescopic pole to its longest operating position
as shown in Figure 6 in the Operation section of this
manual.
n Unscrew the threaded collar from trimmer head base
and pull back over the cord to the extended telescopic
pole as shown.
n Insert the telescopic pole into the trimmer head
threaded base until the lock holes click into place. The
tubes are egg-shaped and will only fit one way. The
threaded base will spread open during assembly.
NOTE: You may need to slightly rotate pole from side
to side until it locks into place.
n Lower the threaded collar onto the threaded base and
rotate clockwise to secure.
WARNING:
Failure to lock telescopic pole as directed above
could result in serious injury or death.

Ryobi RPT400 Specifications

General

Blade size	400 mm
Blade type	Double blade
Product color	Black, Yellow
No-load stroke rate	1700 spm
Engine power	400 W
Power source	AC

Weight and Dimensions

Weight	3000 g
