Samsung ES25 User Manual

034
Ê
Selecting the self-timer
1. Select a Recording mode with the
exception of Voice recording mode.(p.19)
2. Press the Self-timer / Right ( )
button until the desired mode indicator
displays on the LCD monitor. A 10 second,
2 second, Double self-timer or Motion timer
icon appears on the LCD monitor.
3. When you press the shutter button, the
picture will be taken after the specied
time has elapsed.
Self-timer ( ) / Right button
[Selecting the 10 SEC
self-timer]
Ê
Self-timer mode indicator
Icon Mode Description
10 Sec
self-timer
Pressing the shutter button will allow an interval of
10 seconds before the image is taken.
2 Sec
self-timer
Pressing the shutter button will allow an interval of
2 seconds before the image is taken.
Double
self-timer
A picture will be taken after about 10 seconds and
2 seconds later a second picture will be taken.
When using the ash, the 2-second
self-timer may be delayed for longer than 2 sec-
onds depending on the ash charging time.
Motion
Timer
The camera detects the subject's movement 6
seconds after pressing the Shutter button, and the
picture is taken when the movement is stopped.
Ê
The Motion Timer ows are as followings. (Movie mode excluded)
Selecting the Motion Timer
Ã
Pressing the Shutter button
Ã
Conrming the composition (Within 6 sec.)
*1
Ã
Starting the detec-
tion (Swing your hands fully)
*2
Ã
Stopping the detection
(Do not move)
Ã
Taking an image (after 2 sec.)
*1: The camera detects the subject's movement 6 seconds after pressing the
Shtter button, so conrm the composition within 6 seconds.
*2: Move your body or hands fully.
Ê
Motion Timer
Motion Icon & Self-timer lamp
Pressing the Shuter button after
setting the Motion Timer
Blink (1 second interval)
Detecting the subject's movement Blink (0.25 second interval)
No movement is detected
Turn on and the image is taken
after 2 seconds
In the following cases, the Motion Timer may not operate.
å
The focus distance is over 3m.
å
The exposure is too bright or too dark.
å
In backlight conditions.
å
The movement is insignicant.
å
The movement is detected
beyond the center part (50%) of
the sensor where the movement
is recognized.
å
If the camera doesn't sense any
movement for 30 seconds, or the
camera doesn’t sense stillness
after sensing movement.
The detection range of
Motion Timer

Samsung ES25 Specifications

General

Megapixel	12.2 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.3 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Digital zoom	3 x
Optical zoom	4 x
Focal length range	4.9 - 19.6 mm
Interface	USB 2.0, AV out (PAL/ NTSC)
Digital SLR	No
Minimum RAM	256 MB
Minimum processor	Intel Pentium III / 500 MHz+, Power Mac G3+
Dimensions (WxDxH)	96.3 x 23.5 x 61 mm
Camera shutter speed	1/8 - 1/2000 s
Minimum storage drive space	250 MB
Minimum system requirements	CD - ROM DirectX 9.0+
Compatible operating systems	Win 2000 / XP / Vista Mac OS 10.3+
Focal length (35mm film equivalent)	27 - 108 mm
Focus	TTL
Focus adjustment	Auto
Normal focusing range	0.8 - ∞ m
Auto focusing (AF) modes	multi point auto focus, spot auto focus
Macro focusing range (tele)	0.7 - 1 m
Macro focusing range (wide)	0.05 - 0.8 m
Auto Mode focusing range (tele)	0.7 - ∞ m
Auto Mode focusing range (wide)	0.5 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, Auto
Flash modes	auto, fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)	0.5 - 1.59 m
Flash range (wide)	0.2 - 2.68 m
Flash recharging time	4 s
Internal memory	9.8 MB
Compatible memory cards	sd, sdhc
Maximum memory card size	8 GB
Motion JPEG frame rate	30 fps
Video formats supported	AVI
Maximum video resolution	640 x 480 pixels
Display diagonal	2.5 \
Display resolution (numeric)	230000 pixels
USB version	2.0
Product color	Silver
Scene modes	Backlight, beach, Children, Close-up (macro), dusk, Fireworks, Night, Night landscape, Night portrait, Portrait, Sunset, Landscape (scenery)
Image editing	resizing, rotating, trimming
Photo effects	Negative film, Vivid
White balance	auto, Cloudy, custom modes, daylight, Fluorescent, Tungsten
Camera playback	movie, single image, slide show, thumbnails
Power requirements	4.2V
Bundled software	Intelli-Studio CD, Adobe Reader
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Depth	23.5 mm
Width	96.3 mm
Height	61 mm
Weight	114 g
